Product Name/Title: S+S CS7 Control Relay 220 to 250VDC Coil 4NC Contact
Brand: NHP
SKU: CS7E40E220E
Alternatively Known As: Control Relay, Contactor Relay, CS7 Relay
Technical Specifications
- Number of Auxiliary Contacts (NC): 4
- Rated Operation Current (Ie) at 400 V: 20 A
- Max Rated Operation Voltage (UE) AC: 690 V
- Voltage Type for Actuating: DC
- Rated Control Supply Voltage (Us) at DC: 220-250 V
- Power Consumption DC Coil Pickup: 14 W
- Power Consumption DC Coil Hold In: 3 W
- Mounting Method: DIN-rail/screw
- Connection Type Auxiliary Circuit: Screw connection
- Dimensions (H x L x W): 105mm x 86.5mm x 45mm
- Weight: 0.43 kg
Key Features
- 4 Normally Closed (NC) contacts for reliable operation.
- Rated for 20 A operation current at 400 V.
- Designed for DC voltage actuation between 220-250 V.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial automation systems
- Control circuits in machinery
- Safety interlocks
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- Efficient power consumption reduces energy waste.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The S+S CS7 Control Relay 220 to 250VDC Coil 4NC Contact is available now for immediate purchase. Ideal for industrial automation and control applications.
