CS7E04E24E

S+S CS7 Control Relay 24VDC Coil 4NC Contact


$435.10 List price: $577.80
+

Weight: 0.400 kg

Product Name/Title: S+S CS7 Control Relay 24VDC Coil 4NC Contact

Brand: NHP

SKU: CS7E04E24E

Alternatively Known As: Control Relay, Contactor Relay, CS7 Relay

Technical Specifications
  • Number of Auxiliary Contacts (NC): 4
  • Rated Operation Current (Ie) at 400 V: 20 A
  • Max Rated Operation Voltage (Ue) AC: 690 V
  • Voltage Type for Actuating: DC
  • Control Supply Voltage (Us) at DC: 24 V
  • Power Consumption DC Coil Pickup: 10 W
  • Power Consumption DC Coil Hold-in: 1.7 W
  • Mounting Method: DIN-rail/screw
  • Connection Type Auxiliary Circuit: Screw connection
  • Dimensions (H x L x W): 81mm x 87mm x 45mm
  • Weight: 0.4 kg
Key Features
  • 4 Normally Closed Contacts
  • Rated for 20 A operation at 400 V
  • 24 V DC control supply voltage
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Industrial: Automation systems, control panels
  • Commercial: HVAC systems, machinery control
Standards & Compliance
  • Complies with AS/NZS 3000 for wiring rules and AS/NZS 3820 for essential safety requirements.
Environmental Benefits
  • Energy-efficient operation reduces overall power consumption.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The S+S CS7 Control Relay 24VDC Coil 4NC Contact is available now for immediate purchase. Ideal for industrial and commercial applications.

Non-Returnable & Non-Cancellable
