Product Name/Title: S+S CS8 Auxiliary Contact with 2NC Contact
Brand: NHP
SKU: CS8P02E
Alternatively Known As: Auxiliary Contact Block, Control Relay Contact, Mini Auxiliary Contact
Technical Specifications
- Number of contacts: 2 NC
- Rated insulation voltage: 690 V
- Rated operation current at 40°C: 10 A
- Rated operation current at AC 15 24 V: 3 A
- Rated operation current at AC 15 120 V: 3 A
- Rated operation current at AC 15 240 V: 2 A
- Rated operation current at AC 15 400 V: 1.2 A
- Rated operation current at DC 13 24 V: 2.3 A
- Rated operation current at DC 13 110 V: 0.55 A
- Rated operation current at DC 13 220 V: 0.27 A
- Minimum contact rating current: 2 mA
- Minimum contact rating voltage: 15 V
- Mounting method: Top mounting
- Dimensions (H x L x W): 30mm x 70mm x 50mm
- Weight: 0.3 kg
Key Features
- Mini auxiliary contact with 2 normally closed contacts.
- Rated insulation voltage of 690 V.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Control systems, automation equipment
- Commercial: Electrical panels, machinery control
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- Durable design reduces the need for frequent replacements, minimizing waste.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The S+S CS8 Auxiliary Contact with 2NC Contact is available now for immediate purchase. Ideal for control relay applications in industrial and commercial settings.
