CS8P22Z

S+S CS8 Auxiliary Contact with 2NO Contacts and 2NC Contact


$92.40 List price: $122.70
+

Weight: 0.500 kg

Product Name/Title: S+S CS8 Auxiliary Contact with 2NO Contacts and 2NC Contact

Brand: NHP

SKU: CS8P22Z

Alternatively Known As: Auxiliary Contact Block, Control Relay Contact

Technical Specifications
  • Number of Contacts: 2 NO, 2 NC
  • Rated Insulation Voltage: 690 V
  • Rated Operation Current (AC 15, 240 V): 2 A
  • Rated Operation Current (DC 13, 24 V): 2.3 A
  • Min Contact Rating Current: 2 mA
  • Mounting Method: Top mounting
  • Dimensions (H x L x W): 50mm x 100mm x 50mm
  • Weight: 0.5 kg
Key Features
  • 2 Normally Open (NO) and 2 Normally Closed (NC) contacts for versatile control.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Industrial: Control systems, automation equipment
  • Commercial: Electrical panels, machinery control
Standards & Compliance
  • Complies with AS/NZS 3820 for essential safety requirements for electrical equipment.
Environmental Benefits
  • Designed for energy efficiency and reduced operational costs.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The S+S CS8 Auxiliary Contact with 2NO and 2NC Contacts is available now for immediate purchase. Ideal for industrial and commercial control applications.
