Product Name/Title: S+S CS8 Relay 1 and 1 Late Make 1 and 1 Late Break Contacts 110VDC Coil
Brand: NHP
SKU: CS8CL22Z110VDC
Alternatively Known As: Control Relay Mini, CS8 Relay, Contactor Relay
Technical Specifications
- Number of Auxiliary Contacts (NC): 1
- Number of Auxiliary Contacts (NO): 1
- Rated Operation Current (Ie) at 400 V: 10 A
- Max Rated Operation Voltage (UE) AC: 690 V
- Control Supply Voltage (Us) at DC: 110 V
- Power Consumption DC Coil Pickup: 3 W
- Power Consumption DC Coil Hold-in: 3 W
- Mounting Method: DIN-rail/screw
- Connection Type Auxiliary Circuit: Screw connection
- Dimensions (H x L x W): 56mm x 53mm x 45mm
- Weight: 0.2 kg
Key Features
- 1 Normally Closed and 1 Normally Open contact
- 1 Delayed Switching Normally Closed contact
- 1 Leading Normally Open contact
- Rated for 10 A operation at 400 V
- 110 V DC coil voltage
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial automation systems
- Control circuits in machinery
- Building management systems
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- Efficient power consumption with low coil power requirements.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The S+S CS8 Relay 1 and 1 Late Make 1 and 1 Late Break Contacts 110VDC Coil is available now for immediate purchase. Ideal for industrial automation and control applications.
