Product Name/Title: S+S KT7 Motor Protection Circuit Breaker 16 to 20A
Brand: NHP
SKU: KTA745H20A
Alternatively Known As: Motor Protection Breaker, Circuit Breaker 16A, Circuit Breaker 20A
Technical Specifications
- Rated Permanent Current: 20 A
- Max Rated Operation Voltage: 690 V
- Rated Short Circuit Breaking Capacity: 100 kA at 400 V AC
- Rated Operation Power: 10 kW at AC 3, 400 V
- Number of Poles: 3
- Type of Control Element: Turn handle
- Type of Electrical Connection: Screw connection
- Max Tightening Torque: 3.5 Nm
- Dimensions (H x L x W): 111.4mm x 114.5mm x 54mm
- Weight: 0.78 kg
Key Features
- Thermomagnetic switch-off technique for reliable protection.
- Adjustable long-time overload protection from 16 to 20 A.
- IP2X degree of protection ensuring safety against accidental contact.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Motor protection in various machinery and equipment
- Commercial: Electrical installations requiring reliable circuit protection
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
- Enhances energy efficiency by preventing motor overload and potential failures.
Warranty Information
Standard warranty applies, please check with the supplier for details.
Available Now
The S+S KT7 Motor Protection Circuit Breaker 16 to 20A is available now for immediate purchase. Ideal for industrial and commercial applications requiring reliable motor protection.
Non-Returnable & Non-Cancellable
