KTB940H20A

S+S KT9 Motor Circuit Protector KTB9 40H Frame D 20A


$483.10 List price: $641.50
+

Weight: 0.390 kg

Product Name/Title: S+S KT9 Motor Circuit Protector KTB9 40H Frame D 20A

Brand: NHP

SKU: KTB940H20A

Alternatively Known As: Motor Circuit Breaker, Motor Protection Circuit Breaker, Thermal Magnetic Circuit Breaker

Technical Specifications
  • Rated Permanent Current: 20 A
  • Max Rated Operation Voltage: 690 V
  • Rated Operation Power at AC 3, 400 V: 10 kW
  • Number of Poles: 3
  • Degree of Protection: IP2X
  • Max Tightening Torque: 2.5 Nm
  • Type of Control Element: Turn handle
  • Type of Electrical Connection: Screw connection
  • Dimensions (H x L x W): 96.3mm x 93.7mm x 45mm
  • Weight: 0.39 kg
Key Features
  • Thermomagnetic switch-off technique for reliable protection.
  • Rated short-circuit breaking capacity of 100 kA.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Industrial: Motor protection in various machinery and equipment
  • Commercial: Use in commercial electrical installations
Standards & Compliance
  • Complies with AS/NZS 3820 for essential safety requirements for electrical equipment.
Environmental Benefits
  • Complies with AS/NZS 3820 for essential safety requirements for electrical equipment.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The S+S KT9 Motor Circuit Protector KTB9 40H Frame D 20A is available now for immediate purchase. Ideal for industrial and commercial applications.
