SPB140D

Surge Protection Device 1P T2 TNC Uc 275V In 20kA Imax 40kA


$109.70 List price: $140.30
+

Weight: 0.500 kg

Product Name/Title: Surge Protection Device 1P T2 TNC Uc 275V In 20kA Imax 40kA

Brand: Hager

SKU: SPB140D

Alternatively Known As: Surge Protector, Surge Suppressor, SPD, Surge Protection Device

Technical Specifications
  • Capacity: 1 module
  • Voltage protection level Up: 1.35 kV
  • Max. overcurrent protection device: 125 A
  • Network configuration: TN, TT
  • Frequency: 50 - 60 Hz
  • Nominal tightening torque: 3 - 3 Nm
  • Dimensions (H x L x W): 90mm x 66mm x 18mm
  • Weight: 0.5 kg
Key Features
  • Rated operational voltage Ue: 240 - 415 V
  • Continuous operating voltage Uc: 275 V
  • Nominal discharge current In: 20 kA
  • Max discharge (Imax): 40 kA
  • Operating temperature: -40 to 80 °C
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Residential: Homes, apartments, offices
  • Commercial: Retail, hospitality, workspaces
  • General: Any installation requiring surge protection
Standards & Compliance
  • Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
  • RoHS compliant, reducing hazardous substances in electrical equipment.
  • Halogen-free materials contribute to safer disposal and recycling.
Warranty Information

2 years warranty against manufacturing defects.

Available Now

The Hager Surge Protection Device 1P T2 TNC Uc 275V is available now for immediate purchase. Ideal for residential and commercial applications requiring surge protection.
