19MM-SRG2G75F

Surge Protector 2GHz 75Ohm 'F'


$184.40 List price: $240.30
+

Weight: 0.300 kg
Matchmaster has a broad range of band filters, triplexers and diplexers
Matchmaster has block specific filters for blocks A – E plus 694MHz and 652MHz low pass filters for general 4G (LTE) interference reduction
We also offer a range of Isolators and Surge arrestors for 75 Ohm systems up to 3GHz
Designed to be used both indoors and outdoors
View More Filters
DC feed suitable for satellite applications, 90 volt discharge Safeguard electronic equipment from lightning induced surges Suitable for all outdoor antennas Frequency 2 GHz (5-2000MHz)Return loss >= 18dB

Connector
"
F
(Female)"
Frequency Range
2 GHz (5-2000MHz)
VSWR
Less Than 1.5:1
Insertion Loss
Less Than 0.1dB
Discharge Voltage
DC 90V
Max Power Rating
200W
Isolation
3KV-7KV Peak
Return Loss
18dB
