Product Name/Title: Terasaki TemBreak PRO MCCB 160 Frame 36kA 2P 40A Fix. Therm. Fix. Mag.
Brand: NHP
SKU: P160F2240FF
Alternatively Known As: MCCB, Circuit Breaker, Thermal Magnetic Circuit Breaker
Technical Specifications
- Rated Current: 40 A
- Number of Poles: 2
- Max Rated Operation Voltage: 690 V
- Rated Ultimate Short Circuit Breaking Capacity: 36 kA
- Rated Service Short Circuit Breaking Capacity: 36 kA
- Rated Insulation Voltage: 800 V
- Rated Impulse Withstand Voltage: 8 kV
- Over Voltage Category: IV
- Electrical Life: 30,000 cycles
- Mechanical Life: 50,000 cycles
- Cable Cross Section Range: 1.5-70 mm²
- Dimensions (H x L x W): 130mm x 95.5mm x 60mm
- Weight: 0.7 kg
Key Features
- Thermal/magnetic release for reliable protection.
- Fixed thermal and magnetic trip curve.
- Suitable for isolation and front-side connection.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Machinery protection, motor control
- Commercial: Electrical distribution systems
- General: Any application requiring reliable circuit protection
Standards & Compliance
- Complies with AS/NZS IEC 60947.2 for safety and performance standards.
Environmental Benefits
- Designed to operate efficiently in a wide range of temperatures and humidity levels.
Warranty Information
Standard warranty applies.
Available Now
The Terasaki TemBreak PRO MCCB 160 Frame 36kA 2P 40A is available now for immediate purchase. Ideal for industrial and commercial electrical systems.
