Product Name/Title: Terasaki TemBreak PRO MCCB 160 Frame 4P 160A Non Auto Switch
Brand: NHP
SKU: P160D24160NN
Alternatively Known As: Terasaki Circuit Breaker, MCCB 160A, Non Auto MCCB
Technical Specifications
- Rated current: 160 A
- Number of poles: 4
- Max rated operation voltage: 690 V
- Rated frequency: 50-60 Hz
- Rated insulation voltage: 800 V
- Short time withstand current: 2 kA
- Electrical life: 10,000 cycles
- Mechanical life: 20,000 cycles
- Power loss per pole: 9 W
- Cable cross section range: 1.5-70 mm²
- Pollution degree: 3
- Rated surrounding temperature: 50 °C
- Maximum operating temperature: 70 °C
- Dimensions (H x L x W): 130mm x 95.5mm x 120mm
- Weight: 1.3 kg
Key Features
- Rated current: 160 A
- 4 poles for versatile applications
- Non auto-switch type for manual operation
- Suitable for isolation and reverse connection of supply
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Power distribution in manufacturing facilities
- Commercial: Electrical panels in commercial buildings
- General: Protection of electrical circuits in various applications
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installation standards.
Environmental Benefits
- Complies with AS/NZS 60950 for safety and performance standards.
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The Terasaki TemBreak PRO MCCB 160 Frame 4P 160A Non Auto Switch is available now for immediate purchase. Ideal for industrial and commercial power distribution applications.
