Terasaki TemBreak PRO MCCB 630 Frame 70kA 4P 630A Adj. Thermal Adj. Magnetic

$2,860.10 List price: $3,797.80

+ −

30 Days Return Delivery Options

Weight: 6.600 kg

Description

Product Name/Title: Terasaki TemBreak PRO MCCB 630 Frame 70kA 4P 630A Adj. Thermal Adj. Magnetic

Brand: NHP

SKU: P630H4630TM

Alternatively Known As: MCCB, Molded Case Circuit Breaker, Circuit Breaker 630A

Technical Specifications

Rated Current: 630 A
Number of Poles: 4
Max Rated Operation Voltage: 690 V
Rated Ultimate Short Circuit Breaking Capacity: 70 kA
Rated Service Short Circuit Breaking Capacity: 70 kA
Type of Protection: Thermal/magnetic release
Trip Curve: Adjustable thermal, adjustable magnetic
Long Time Overload Protection Adjustment Range: 400-630 A
Instantaneous Protection Adjustment Range: 2520-5040 A
Rated Frequency: 50-60 Hz
Rated Insulation Voltage: 800 V
Rated Short Circuit Breaking Capacity (ICU): 12 kA
Rated Short Circuit Breaking Capacity (ICS): 12 kA
Rated Impulse Withstand Voltage: 8 kV
Over Voltage Category: IV
Power Loss per Pole: 62.3 W
Mechanical Life: 15000 cycles
Electrical Life: 4000 cycles
Cable Cross Section Range: 35-400 mm²
Dimensions (H x L x W): 260mm x 151mm x 185mm
Weight: 6.6 kg

Key Features

Adjustable thermal and magnetic trip settings for customized protection.
High breaking capacity of 70 kA for reliable circuit protection.
Suitable for isolation and front-side connection.

Professional Installation Requirements

Professional installation by a qualified electrician is recommended for optimal safety.

Applications

Industrial: Power distribution in manufacturing facilities
Commercial: Electrical installations in large buildings
General: Protection of electrical circuits from overload and short circuits

Standards & Compliance

Complies with AS/NZS IEC 60947.2 for safety and performance standards.

Environmental Benefits

Designed to operate efficiently within a wide temperature range, reducing energy loss.

Warranty Information

Standard warranty as per manufacturer guidelines.

Available Now

The Terasaki TemBreak PRO MCCB 630 Frame 70kA 4P 630A is available now for immediate purchase. Ideal for industrial and commercial electrical installations.
