HV19092T-BR

Viale Brass TRI Colour LED Four Way Driveway Light


$251.90 List price: $328.00
+

Weight: 1.500 kg

Product Name/Title: Viale Brass TRI Colour LED Four Way Driveway Light

Brand: Havit

SKU: HV19092T-BR

Alternatively Known As: Four Way Driveway Light, TRI Colour LED Light, Recessed Outdoor Light

Technical Specifications
  • Input Voltage: 12V DC
  • Power Wattage: 5W
  • Lumens Output: 270lm, 285lm, 300lm
  • IP Rating: IP65
  • IK Rating: IK10
  • Included LED: 5W 12V DCMR16 LED
  • Dimensions (H x L x W): 100mm x 100mm x 100mm
  • Weight: 1.5 kg
Key Features
  • Recessed design suitable for outdoor use.
  • Brass face with Antique Brass Finish.
  • Full Body Stainless Steel 316 Marine Grade.
  • Tempered Glass for durability.
  • TRI Colour options: 3000k, 4000k, 5500k.
  • IP65 rated for water and dust resistance.
  • IK10 rated for impact resistance.
Professional Installation Requirements
  • Must be used with a suitable 12V DC LED driver; professional installation is recommended.
Applications
  • Residential: Driveways, pathways, gardens
  • Commercial: Outdoor spaces, parking lots, public areas
Standards & Compliance
  • Complies with AS/NZS 3000 for electrical installation safety.
Environmental Benefits
  • Energy-efficient design with 5W MR16 LED globe reduces power consumption.
Warranty Information

3 years replacement warranty for items ordered after 01/01/22.

Available Now

The Viale Brass TRI Colour LED Four Way Driveway Light is available now for immediate purchase. Ideal for enhancing outdoor spaces with stylish and functional lighting.

Data Sheet (HV19092T-AB_Data_Sheet.pdf, 610 Kb) [Download]

Installation Instructions (HV19062T-HV19092T_Installation_Instructions_FEB24.pdf, 243 Kb) [Download]


Lighting Requirement Calculator







This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
